1, the audio matrix can switch between 8 audio inputs and 8 audio outputs
2, 1 V balanced input and 500 m V unbalanced input port for user access
3, the same source (such as C D, radio, deck and other audio sources) with the system host online, you can set the audio management software matrix
Enter 8-CHANNEL 500mV / 10KΩ Unbalanced
8-CHANNEL 1V / 10KΩ Balanced
Output 1V / 600Ω Balanced
Signal to noise ratio ≧ 75dB
Power AC 220V / 50Hz,
Power consumption ≦ 20W
Net weight 4.80kg
Gross weight 6.20kg
Body size 482 × 88 × 290mm
