1, with automatic / manual broadcast control
2, to provide 2 recording interface, MIC and LINE
3, FM radio with high sensitivity FM radio function
4, with 4 programmable AC220V power output, power timing function
5, 4-way partition control port, used to achieve the timing partitioning function
6, the machine built-in 2G memory, expandable external memory card, up to 32G
7, storage: memory card FLASH
8, provide XLR (balanced) and Lotus (unbalanced) output socket
FM 88-108MHz
Recording input LINE IN 250mV Unbalanced
MIC 5Mv Balanced
Output 1V / 600Ω Balanced
500mV / 600Ω Unbalanced
Frequency response 20Hz ~ 20KHz ± 3dB
Total harmonic distortion (1K signal test) ≦ 0.1% (1KHz)
Signal to noise ratio ≧ 85dB
Power AC220V / 50Hz,
Exchange power ≦ 20W
Net weight 6.15kg
Gross weight of 7.85kg
Body size 482 × 88 × 290mm
