1, with 16 intelligent control signal output and Fire Center linkage input port, online expansion
2, with automatic fire linkage function (broadcast area N - 1, N, N +1 with digital signal transmission, the relevant peripherals (such as: C K - 5 1 6 D paging microphone)
After the information is collected, analyzed and processed, the working status of the system is automatically notified to the related peripheral devices, the whole system is controlled by the priority of manual / automatic emergency firefighting broadcasting and paging microphone broadcasting, and meanwhile, the information of each channel Working status, the user can pass this device
3, according to the actual needs of the flexible control of the work of all regions
4. Analyze and process the information after controlling C K-8 0 1 0 E Emergency switch open the corresponding audio channel, at the same time output short circuit and D C 2 4 V two kinds of output signals, control the corresponding area of amplifier and sound control cut
5, change to the priority strong cut state, to achieve emergency firefighting broadcast or district paging broadcast
6, can be online with the system host, real-time reflection of fire collection status
Short circuit input port number 16CH
Short circuit output port number 16CH
DC24V output port number 16CH
Power AC220V / 50HZ
AC power consumption ≤ 20W
Net weight 5.0kg
Gross weight 6.5kg
Body size 482 * 88 * 290mm
